Verification and Calibration Appendix B
Series N5700 User’s Guide 109
Test Record Form – Agilent N5749A and N5769A
Agilent N5749A and N5769A Report No _______________ Date __________________
Description Model Minimum Specs. Results Maximum Specs.
Voltage Programming & Readback
Minimum Voltage Vout
Measurement Readback
High Voltage Vout
Measurement Readback
Both
Both
Both
Both
0 mV
Vout − 100 mV
99.9 V
Vout − 200 mV
__________
__________
__________
__________
+ 250 mV
Vout + 100 mV
100.1 V
Vout + 200 mV
CV Load Effect Both − 12 mV __________ + 12 mV
CV Source Effect Both − 12 mV __________ + 12 mV
CV Ripple and Noise
peak-to-peak
rms
Both
Both
N/A
N/A
__________
__________
80 mV
8 mV
Transient Response
Voltage @ 1ms
Both
− 500 mV
__________
+ 500 mV
Current Programming & Readback
Minimum Current Iout
Measurement Readback
High Current Iout
Measurement Readback
N5749A
N5769A
N5749A
N5769A
N5749A
N5769A
N5749A
N5769A
0 mA
0 mA
Iout − 22.5 mA
Iout − 45 mA
7.485 A
14.97 A
Iout − 30 mA
Iout − 60 mA
__________
__________
__________
__________
__________
__________
__________
__________
+ 38 mA
+ 76 mA
Iout + 22.5 mA
Iout + 45 mA
7.515 A
15.03 A
Iout + 30 mA
Iout + 60 mA
CC Load Effect
N5749A
N5769A
− 6.5 mA
− 8 mA
__________
__________
+ 6.5 mA
+ 8 mA
CC Source Effect
N5749A
N5769A
− 2.75 mA
− 3.5 mA
__________
__________
+ 2.75 mA
+ 3.5 mA
Test Description N5749A Setting N5769A Setting
Voltage Programming & Readback, Min Voltage ≤200 mV, 30 mA ≤200 mV, 60 mA
Voltage Programming & Readback, High Voltage 100 V, 30 mA 100 V, 60 mA
CV Load Effect, Source Effect, Ripple and Noise 100 V, 7.5 A 100 V, 15 A
Transient Response
100 V, from 0.75 A to 6.75 A
100 V, from 1.5 A to 13.5 A
Current Programming & Readback, Min Current 30 mA, 100 V 60 mA, 100 V
Current Programming & Readback, High Current 7.5 A, 100 V 15 A, 100 V
CC Load Effect, Source Effect 7.5 A, 100 V 15 A, 100 V
Load Requirements N5749A N5769A
Current shunt 0.1Ω 15 A 0.1Ω 15 A
Agilent N3300 Electronic load modules 2 – N3305A 3 – N3305A
Fixed Resistor for CV Ripple and Noise 13.33Ω 1kW 6.67Ω 2kW
