5Key Reference
120 N9342C/43C/44C User’s Guide
Table 1 Offsets & Limits Defaulted for
W-CDMA (3GPP)
Base Station Measurements
a
a. Fail Mask is set to Absolute and Rel Stop is set to Couple.
Table 2 Offsets & Limits Defaulted for W-CDMA (3GPP)
Mobile Station Measurements
a
a. Abs Stop is set to Couple and Fail Mask is set to Abs AND Rel.
Table 3 Offsets & Limits Defaulted for 802.11a and
HiperLAN/2 Radio Standards
a
a. Fail Res BW is set to 100 kHz and Fail Mask is set to Rel.
Offset Start
Freq
(MHz)
Stop
Freq
(MHz)
Res
BW
(kHz)
Abs
Start
(dBm)
Abs
Stop
(dBm)
Abs
Couple
Rel
Start
(dBc)
Rel
Stop
(dBc)
Meas
BW
A. On 2.515 2.715 30.00 -14.00 -14.00 Couple -30.00 -30.00 1
B. On 2.715 3.515 30.00 -14.00 -26.00 Man -30.00 -30.00 1
C. On 3.515 4.000 30.00 -26.00 -26.00 Couple -30.00 -30.00 1
D. On 4.000 8.000 1000.00 -13.00 -13.00 Couple -30.00 -30.00 1
E. On 8.000 12.500 1000.00 -13.00 -13.00 Couple -30.00 -30.00 1
Offset Start
Freq
(MHz)
Stop
Freq
(MHz)
Res
BW
(kHz)
Abs
Start
(dBm)
Abs
Stop
(dBm)
Rel
Couple
Rel
Start
(dBc)
Rel
Stop
(dBc)
Meas
BW
A. On 2.515 3.485 30.00 -71.07 -71.07 Man -35.23 -49.78 1
B. On 4.000 7.500 1000.0 -55.84 -55.84 Man -35.50 -39.00 1
C. On 7.500 8.500 1000.00 -55.84 -55.84 Man -39.00 -49.00 1
D. On 8.500 12.000 1000.00 -55.84 -55.84 Couple -49.00 -49.00 1
E. Off 12.500 15.000 1000.00 -55.84 -55.84 Couple -49.00 -49.00 1
Offset Start
Freq
(MHz)
Stop
Freq
(MHz)
Abs
Start
(dBm)
Abs
Stop
(dBm)
Abs
Couple
Rel
Start
(dBc)
Rel
Stop
(dBc)
Rel
Couple
Meas
BW
A. On 9.00 11.00 16.00 -4.00 Man 0.00 -20.00 Man 1
B. On 11.00 20.00 -4.00 -12.00 Man -20.00 -28.00 Man 1
C. On 20.00 30.00 -12.00 -24.00 Man -28.00 -40.00 Man 1
D. On 30.00 50.00 -24.00 -24.00 Couple -40.00 -40.00 Couple 1
E. Off 50.00 100.00 -24.00 -24.00 Couple -40.00 -40.00 Couple 1
