Setup and Calibration of the CP-8400/8410
CP-8400 AutoSampler & CP-8410 AutoInjector 21
Injector Calibration
CP-8400 INJ 1 CALIB
ACTIVE
METHOD
EDIT
METHOD
CTRL
RUN
TIME
END
TIME
Component
Tower
Direction 1
CCW
Direction 2
CW
Syringe Up Down
Move Finish Calib.Start Calib.
To calibrate the Injector 1 and Injector 2 Positions, perform the following
steps:
1. Press the Start Calib. softkey. The CP-8400/8410 will rotate the
tower so that it is over the Injector 1 position and lower the
syringe sled so that it is over the injector. If the needle guide
descends so that it is either resting on the inject switch or below
the needle cone on the inject switch, use the scroll key to
highlight the Syringe up and move the sled up by highlighting the
Up selection and pressing the Move softkey until the needle
guide is just above the injector cone.
2. Using the cursor keys at the right top corner of the CP-3800
keypad, highlight either the CCW (rotates the tower
counterclockwise 10 steps) or CW (rotates the tower clockwise 1
step). Position the tower directly over the injector Inject Switch
Locator cone.
3. Scroll to the syringe setting and adjust the height of the needle
guide such that the sled is just resting on or very slightly
depressing the Injector Switch and is covering the locator cone.
