6 03-914852-00:4
4. If the Injector locator plate is installed in the top cover, remove it
by removing the two screws located on either end of the locator
plate. Install the top cover so that the pins on the top cover fit
into the corresponding slots on the CP-3800 chassis. Screw the
top cover in place.
5. Install the Injector locator plate by fitting the circular holes over
the injectors. You may need to push the locator plate just a little
bit in order to get the injectors to fit. Do not use excessive force.
If the injectors do not fit conveniently, loosen the screws holding
the injector(s) to the CP-3800 chassis and adjust the injector(s)
positions so that they conveniently fit into the locator plate. The
top cover has small access holes to allow you to loosen the
retaining screws on the injectors. You may need to unscrew the
injector nut and remove the inject switch to have unimpeded
access to the injector retaining screws; replace the injector nut (if
removed) so that you have proper alignment when the locator
plate is installed. Once the injector(s) are properly aligned, screw
down the alignment plate and then screw down the injector
retaining screws. Remove the locator plate, replace the inject
switch on each of the injector(s) and reinstall the locator plate.
6. Place the CP-8400/8410 onto the top cover, aligning it with either
the front or rear mounting position as appropriate. Locate and
install the two small screws provided with your CP-8400/8410
and screw down the rear tab.
7. Locate the three long screws and install in appropriate screw
location under the carrousel (note that the CP-8410 does not
have the rollers or central hub but will have the same screw
locations).
