Electrical Interfaces
AGD301 Product Manual Rev.2.0 Page 50
DIP Switches
DIP
Switch #
Function Description
1 CAN Bus Terminator
Set to ON to connect 120Ω terminator resistor. Only the last
unit in the CAN network needs to have this set to ON.
2 Force Download
Firmware
Set to ON and power cycle to force the product into firmware
download mode. Otherwise, always keep in OFF state.
3 Force Communication to
Default
Forces the controller to default communication parameters
(bypassing other software parameters in the controller):
Ethernet IP: 172.1.1.101
Ethernet Port: 50000
CAN Address: 64
CAN and RS232/USB baud rates are not affected by this DIP
switch. Requires power cycle or reset.
4-6 CAN/Ethernet Address
Offset
DIP Switch 4 – Most
significant bit
DIP Switch 6 – Least
significant bit
DIP switches 4-5-6 create a three-bit value.
For example, if DIP switch 4 is set to ON (value of 1), and 5 and
6 are set to OFF (value of 0), the result is: 100 (binary),
meaning a value of 4.
This value (referred to as offset) is used to define the drive’s
CAN bus address and Ethernet IP address as follows:
Ethernet IP: the actual fourth number of the IP address is equal
to: EthernetIP [4] + offset
CAN address: the actual CAN address of the unit is equal to:
CANAddr + offset * 16
Note: Requires power cycle or reset.
7 Reserved for Future Use Always keep at OFF state.
8 Reserved for Future Use Always keep at OFF state.
