3 COMPONENTS
1. Visor opening button
2. Chin guard central air intake vent
3. Chin guard lateral air intake vents
4. Chin guard opening button
5. Nose guard
6. Sun visor
7. Eccentric pawl for fastening
and tensioning the Pinlock
®
lens
8. Visor mechanism
9. Spring-loaded visor release slider
10. Upper air intake
11. Upper exhaust vents
12. Intercom housing cover
(1)
with integrated lower exhaust vents
13. Micrometric fastening system
14. Intercom button panel
(1)
cover
15. Sun visor operation slider
16. Crown pad
17. Crown pad attachment plastic clips
18. Crown pad attachment snap button
19. Cheek pad
20. Cheek pad attachment snap button
21. Cheek pad attachment sliding guide
8
8
1
1
3
3
5
5
9
9
10
10
6
6
7
7
4
4
11
11
14
14
13
13
12
12
15
15
17
17
16
16
18
18
19
19
20
20
21
21
20
20
20
20
20
20
2
2
РУ
中文中文
(1)
Accessory not included. Please see 2.3

AGV Tourmodular Specifications

General

Safety Standard	ECE 22.05
Type	Modular Helmet
Shell Material	Carbon-Aramid-Fiberglass
Interior	Removable and Washable
Visor	Pinlock Ready
Weight	1620 g in first shell size
Sun Visor	Integrated
Retention System	Micrometric Retention System
Communication System	Ready for AGV communication system
Ventilation	Adjustable air vents (5 front, 1 rear)
