RACE STUDIO 3 SOFTWARE
40 41
EVO5
CHAPTER 11
11.1.2
ECU Stream and CAN resistor
configuration
CAN resistor configuration
11.1.3 CAN2 Stream
Push "ECU Stream" tab.
Here you set the ECU driver as well as ena-
ble or disable the data coming from your
ECU and enable/disable the ending 120
Ohm CAN1 resistor.
To set the ECU driver of your vehicle
click "Change ECU" and select ECU
Manufacturer and ECU Model.
A CAN line ending with a 120 Ohm resistor
can be enabled/disabled thr
ough this
checkbox.
Push the tab "CAN2 Stream".
CAN2 Stream works like ECU Stream and is
normally used for non engine control units
like for example ABS management, suspen-
sion kits or similar.
Each ECU channel can be enabled/
disabled and you can define:
n
Name
n
Sampling frequency
n
Unit of measure
n
Display precision
