Aiphone AX-248C User Manual

- 11 -
3-5
Wiring distance
3-4
Cable
1. CAT5e (24AWG) straight-thru EIA/TIA 568B
1 White-orange
2 Orange
3 White-green
4 Blue
5 White-blue
6 Green
7 White-brown
8 Brown
2. Ø 0.8 to 1.6 mm (20 to 14 AWG)
1. In order to prevent mis-wiring, label each incoming cable
with its station location/name.
2. Do not pull or put excess strain on the CAT5e cable. The
maximum tension on the cable is set to 11.2 kg (110 N).
AX-DM
IF-DA
IE-JA
IE-SS
AX-DV
AX-DVF
AX-DV-P
AX-DVF-P
AX-320C
AX-320C
AX-084C
AX-248C
+ AX-16SW
M
D
E1
E4
E2
AX-320C
E3
A
B
C
AX-8M
AX-8MV
PS-2420UL
PS-2420S
PS-2420DIN
PS
D
AX-248C
AX-320C
AX-320C
AX-320C
RJ-45 Plug
Pin 1
12345678 12345678
1
2
CAT5e
CAT5e
CAT5e
2
AX-DM IF-DA
AX-DV AX-DV-P AX-DVF AX-DVF-P
AX-320C
AX-084C
AX-248C
PS-2420UL
PS-2420S
PS-2420DIN
AX-8M AX-8MV
IE-JA IE-SS
AX-084C
AX-248C
PS
AX-248C
AX-320C
AX-248C
-
-
10 m (33')
-
A
B
C
D
CAT5e (24AWG) Ø0.8 ~ 1.6 mm (20 ~ 14AWG)
300 m (980')
300 m (980')
-
5 m (16')
