- 43 -
9
TECHNICAL PRECAUTIONS
Technical precautions
• Operating temperature:
Door station: -10 ~ 60 °C (14 ~ 140 °F)
Master station: 0 ~ 40 °C (32 ~ 104 °F)
Central exchange unit: 0 ~ 40 °C (32 ~ 104 °F)
• Cleaning: Clean the units with a soft cloth dampened with a
neutral household cleanser. Do not use an abrasive
cleaner or cloth.
• Camera switching:
Since the individual camera sync signal is a non-
synchronized signal, the image synchronization may
be disrupted. Also, the time until synchronization is
re-established depends on the display device used.
Specifications
•Power supply: DC 24 V, 2 A
(Two Power supply required per video system)
•Current consumption:
AX-084C: Video (Max.) 620 mA, Audio (Max.) 650 mA
AX-248C: Video (Max.) 1100 mA, Audio (Max.) 1250 mA
AX-320C: Video (Max.) 200 mA, Audio (Max.) 180 mA
•Communication: <Auto> VOX
<Manual> Press-to-talk, Release-to-listen.
•Camera: CCD 250,000 pixels
•Video monitor: 3-1/2" direct view TFT color LCD
•Scanning lines: 525 lines.
•Door release contact: 24 V AC/DC, 0.5 A
•Dimensions:
AX-DM: 43(W) x 160(H) x 22.5(D) mm
1-11/16"W x 6-5/16"H x 7/8"D
AX-DV: 100(W) x 195(H) x 25(D) mm
3-15/16"W x 7-11/16"H x 1"D
AX-DVF: 146(W) x 246(H) x 47(D) mm
5-3/4"W x 9-11/16"H x 1-7/8"D
AX-DV-P: 100(W) x 230(H) x 25(D) mm
3-15/16"W x 9-1/16"H x 1"D
AX-DVF-P: 146(W) x 295(H) x 47(D) mm
5-3/4"W x 11-5/8"H x 1-7/8"D
AX-8M: 194(W) x 175(H) x 48(D) mm
7-5/8"W x 6-7/8"H x 1-7/8"D
AX-8MV: 194(W) x 175(H) x 48(D) mm
7-5/8"W x 6-7/8"H x 1-7/8"D
AX-16SW: 86(W) x 175(H) x 48(D) mm
3-3/8"W x 6-7/8"H x 1-7/8"D
AX-084C: 480(W) x 88(H) x 335(D) mm
1'6-7/8"W x 3-7/16"H x 1'1-3/16"D
AX-248C: 480(W) x 88(H) x 335(D) mm
1'6-7/8"W x 3-7/16"H x 1'1-3/16"D
AX-320C: 480(W) x 88(H) x 335(D) mm
1'6-7/8"W x 3-7/16"H x 1'1-3/16"D
•Weight:
AX-DM: 100g (0.22 lbs.) approx.
AX-DV: 400g (0.88 lbs.) approx.
AX-DVF: 660g (1.45 lbs.) approx.
AX-DV-P: 450g (0.99 lbs.) approx.
AX-DVF-P: 760g (1.67 lbs.) approx.
AX-8M: 450g (0.99 lbs.) approx.
AX-8MV: 550g (1.21 lbs.) approx.
AX-16SW: 200g (0.44 lbs.) approx.
AX-084C: 4,700g (10.35 lbs.) approx.
AX-248C: 4,700g (10.35 lbs.) approx.
AX-320C: 4,700g (10.35 lbs.) approx.
• Central exchange unit (AX-084C, 248C):
Outside video output: NTSC standard 1 Vpp (0.7-1.4 Vpp)
BNC(2)
Outside video output unit: Open collector output
DC24V, 30mA
RJ45(2)
•Master station (AX-8MV):
Outside video output: NTSC standard 1 Vpp (0.7-1.4 Vpp)
10
SPECIFICATIONS
