Aiphone AX-248C User Manual

- 9 -
2-4
Package contents (16 call add-on selector)
[1] AX-16SW 16-call add-on selector
[2] Mounting screws
[3] Joint bracket x2
[4] Connector cable
[5] Screws for connecting master and add-on selector
2-3
Package contents (Master station)
[1] AX-8M audio master station, AX-8MV color video master
station
[2] Mounting screws
[3] Mounting bracket
[4] Optional connector (6-pin)
[5] Tie wrap (when optional connector is used with desktop
installation)
2-5
Package contents (Central exchange unit)
[1] AX-084C, AX-248C, or AX-320C exchange unit
[2] Mounting screws
[3] Rack and wall mounting brackets x2
[4] Installation CD (AX-084C, AX-248C), including set-up
software program and instruction manual.
[5] Mounting screws (for 19-inch rack mounting)
[1] [2]
[3] [5][4]
[1] [2] [3]
[4] [5]
[1] [2] [3]
[4]
[5]

Aiphone AX-248C Specifications

General

Brand	Aiphone
Model	AX-248C
Category	Security System
Language	English
