Air Techniques MOJAVE LT3 - SPECIFICATIONS

Page 5Air Techniques, Inc. Air Techniques, Inc. Page 4
To ensure optimum operation, the demands should not exceed the number of vacuum users shown
below. The chart lists the number of simultaneous High Volume Evacuators (HVEs) and Saliva
Ejectors (SEs) that can be used by the MOJAVE LT3 system.
SIZING GUIDE
SPECIFICATIONS
Pump Electrical Specifications LT3
Voltage (Volts AC ± 10%)
220
Full Load Current (Amps AC) 15
Input Frequency (Hz) 50/60
Preset Vacuum Level (InHg) 8
Horsepower 1.1 kW or 1.5 HP
System Environmental Conditions (All Systems)
Operating Temperature 50 to 105°F or 10 to 40°C
Storage and Transport Temperature 32 to 158°F or 0 to 70°C
Operating Relative Humidity 80%, no condensation
Storage and Transport Relative Humidity 90%, no condensation
UL60601-1 CLASSIFICATION
Protection against electrical shock (5.1, 5.2) Class I, Transportable,
Continuous Operation. No applied parts. Protection against ingress
of liquids-Ordinary Equipment not suitable for use in the presence of
flammable anaesthetic mixture with air or with oxygen or nitrous oxide.
All MOJAVE LT3 vacuum pumps comply with NFPA 99C level 3 requirements.
Recommended Number of Simultaneous HVE/SE Users
HVE SE
3
+ 0
2 + 2
1 + 4
0 + 6
Note: 1 HVE = 2 SE’s
1 HVE = 2 Nitrous Scavengers
