Site Requirements
Electrical Requirement
Voltage Rating Volts AC 220 Volts, Single Phase AC, 50/60 Hz
Voltage Minimum/Maximum 198/242 Volts AC
Wire Size AWG Minimum Gauge #12 AWG
Minimum Circuit Breaker Rating 20A
Incoming Power
Hard wire Connection
(unit is supplied a 6 foot BX cable)
Remote (Low Voltage Wiring)
#18 AWG Wire Connection between the pump and
the Remote Switch Panel .
Plumbing
Requirement
Exhaust Vent Pipe
1 ½
”
PVC Sch. 40
Minimum Suction Line Pipe 1
”
PVC Sch. 40
Maximum Suction Line Pipe
(See note 2)
1 ½
”
PVC Sch. 40
Riser Pipe ½
”
PVC Sch. 40
Vacuum Line Termination 1 ½
”
Spigot
Branch Line Pipe
Size requirement of Branch piping differs by the number of
treatment rooms being serviced.
* Up to three rooms; use 1" PVC Schedule 40.
Four to six rooms; use 1 ½
”
PVC Schedule 40.
Drain Hose
1" Corrugated
NOTES
1. Recommended for all new installations.
2. Use maximum internal diameter for the main line when preparing any new installation.
Recommended Space Requirement
Unit Dimensions:
Height 20 in. (51 cm)
Width 24 in. (61 cm)
Depth 16.5 in. (42 cm)
INSTALLATION INFORMATION
