EB AT-RP-4GU EN 9-3
Service
PART N°
1)
UNIT Q.TY NOTE DESCRIPTION
05* ◊ 2 BEARING (Piston back)
06* ◊ 1 BEARING (Pinion top)
07* ◊ 1 BEARING (Pinion bottom)
08* ◊ 2 1 pcs for AT045U THRUST BEARING (Pinion)
09* ◊ • 2 N.A. for AT801U PLUG
09.1* ◊ • 2 O-RING (For AT801U)
10 1 THRUST WASHER (Pinion)
11* ◊ • 2 N.A. for AT045U O-RING (Stop screw)
11R* ◊ • 2 for models with extra travel stop adjustment O-RING (Extra travel stop adjustment screw)
12 2 N.A. for AT045U PISTON GUIDE
13
2)
8/12/16 CAP SCREW (End cap)
14* ◊ • 2 O-RING (End cap)
15* ◊ 2 BEARING (Piston head)
16* ◊ • 2 O-RING (Piston)
17 min. 5/ max. 12 SPRING (Cartridge)
17.1
max. 2 for AT045U
max. 2 for AT051U
SPRING (for AT045U ÷ AT051U)
17.2 SPRING (for AT045U ÷ AT051U)
17.3 SPRING (for AT045U ÷ AT051U)
18 1 SPRING CLIP (Pinion)
19 1 POSITION INDICATOR (for AT045U ÷ AT101U)
19.0 1 GRADUATED RING
19.1 1 N.A. for AT045U ÷ AT101U POSITION INDICATOR
19.2
3)
1 MULTIFUNCTION POSITION INDICATOR
19.5 1 N.A. for AT045U ÷ AT101U TOP ADAPTER (Drive shaft)
19.6 2 N.A. for AT045U ÷ AT101U HEX. SOCKET SCREW (Top adapter)
20* ◊ • 1 O-RING (Pinion bottom)
21* ◊ • 1 O-RING (Pinion top)
30 2 END CAP
39 1 CAP SCREW (Indicator)
40 2 PISTON
41 1 ACTUATOR INDENTIFICATION LABEL
42 2 only for AT045U and AT751U END CAP LABEL
43
3)
1 SPIGOT
50 1 BODY
60 1 DRIVE SHAFT
60.1 1 INTEGRAL DRIVE SHAFT
65 1 PLASTIC INSERT
221G 2 for models with 50% extra travel stop adj. STOP SCREW (Extra travel stop adjustment)
222G 2 for models with 100% extra travel stop adj. STOP SCREW (Extra travel stop adjustment)
NOTES:
1) * Suggested spare parts.
Components included in spare part kits are indicated as follows:
◊ included in complete spare parts kit
• included in o-rings kit
2) 8 for AT045U ÷ AT101U; 12 for AT701U ÷ AT751U; 16 pcs for AT801U
3) Available on request.
