Air Torque AT551U - Tightening Torque

EB AT-RP-4GU EN 15-3
Annex
15.2 Tightening torques
− All the tightening torques are intended in Nm.
− Tightening torque tolerance: ±10%.
− The tightening torques are based on a friction coefficient of 0.12 with a lubricated fixing elements (bolts or nuts) threads.
− After long operating times or use at temperatures above 80°C, the breakaway torque may be significantly higher.
Table 15-1: End cap screws (13)
ACTUATOR MODEL THREAD TIGHTENING TORQUE (Nm)
AT045U
M5 4 ÷ 5
AT051U
AT101U
M6 7 ÷ 8AT201U
AT251U
AT301U
M8 18 ÷ 20
AT351U
AT401U
M10 34 ÷ 36
AT451U
AT501U
M12 60 ÷ 64
AT551U
AT601U M14 96 ÷ 102
AT651U M16 150 ÷ 160
AT701U M14 96 ÷ 102
AT751U
M16 150 ÷ 160
AT801U
Table 15-3: Stop screws nuts (04)
ACTUATOR MODEL THREAD TIGHTENING TORQUE (Nm)
AT051U
M6 8 ÷ 9
AT101U
AT201U
M8 18 ÷ 20
AT251U
AT301U M10 34 ÷ 36
AT351U
M12 60 ÷ 64
AT401U
AT451U
M14 96 ÷ 102
AT501U
AT551U M16 150 ÷ 160
AT601U
M20 290 ÷ 310
AT651U
AT701U M24 235 ÷ 250
AT751U
M30 470 ÷ 500
AT801U
Table 15-2: Extra travel stop adjustment nuts (04R)
ACTUATOR MODEL THREAD TIGHTENING TORQUE (Nm)
AT051U
M6 8 ÷ 9
AT101U
AT201U
M8 18 ÷ 20
AT251U
AT301U M10 34 ÷ 36
AT351U
M12 60 ÷ 64
AT401U
AT451U
M14 96 ÷ 102
AT501U
AT551U M16 80 ÷ 86
AT601U
M20 160 ÷ 170
AT651U
AT701U M24 270 ÷ 290
AT751U
M30 540 ÷ 570
AT801U
Table 15-4: Pressure connection
ACTUATOR MODEL THREAD TIGHTENING TORQUE (Nm)
AT045U
M5 4 ÷ 5
AT051U
AT101U
AT201U
AT251U
AT301U
AT351U
AT401U
AT451U
AT501U
AT551U
AT601U
AT651U
M6 8 ÷ 9
AT701U
AT751U
AT801U
