15-2 EB AT-RP-4GU EN
Annex
− Extra travel stop adjustment screws tools (50% and 100% adjustment)
Fig. 15-3
ACTUATOR
MODEL
221G/222G 04R
TYPE Ch 3 (mm) Ch 4 (mm)
AT051U
A
3
8
AT101U 10
AT201U
4
10
AT251U 10
AT301U 5 13
AT351U
B
8
13
AT401U 17
AT451U
10
17
AT501U 19
AT551U 19
AT601U
13
22
AT651U 24
AT701U 17 22
AT751U
22
24
AT801U 24
Ch 3
− Type A
− Type B
221G
222G
221G
222G
Ch 4
04R
Ch 3
