Air Torque AT551U - Part List

9-2 EB AT-RP-4GU EN
Service
9.2 Part list
41
08*0105* 41 02 04 03 11* 08* 10 39
19.1 19.0 18 50
43
60.1
20*
07*
60
19.6
19.5
65
06*
21*
17
19
17.1
17.2
17.3
09*124016*15*1714*
30
30R
13
Fig. 9-1
04R
03R
11R
221G
222G
19.2
Table 9-2
PART N°
1)
UNIT Q.TY NOTE DESCRIPTION
01 1 N.A. for AT045U OCTI-CAM (Stop arrangement)
02 2 N.A. for AT045U STOP CAP SCREW
03 2 N.A. for AT045U WASHER
03R 2 for models with extra travel stop adjustment WASHER
04 2 N.A. for AT045U NUT (Stop screw)
04R 2 for models with extra travel stop adjustment NUT (Extra travel stop adjustment screw)
