| VF, DHT, AES Series Manual
Refrigerated Air Dryer User Manual
10
Model by SCFM
Rating Refrigeration HP
Cooling Air Flow
(cfm)
10, 15, 25 0.20 275
40, 50 0.25 300
60, 75 0.33 300
100 0.50 350
125, 150 0.75 525
200 1.25 750
250, 300 1.50 1,250
400 2 3,000
500, 600 3.50 3,000
800, 1000 5 5,000
1,200 6 5,000
1,600 7 6,000
2,000 10 6,000
Model by SCFM
Rating Refrigeration HP
Cooling Air Flow
(cfm)
20 0.33 300
40 0.50 350
50 0.50 350
75 0.75 525
100 0.75 525
125 1.25 750
TABLE 3-1: Air-Cooled Cooling Air Flow -
VF Series
TABLE 3-2: Air-Cooled Cooling Air Flow -
DHT Series
TABLE 3-3: Air-Cooled Cooling Air Flow -
AES Series
Model by SCFM
Rating Refrigeration HP
Cooling Air Flow
(cfm)
600 3.0 3,000
800 4.0 4,500
1,000 5.0 5,000
1,250 6.0 5,000
1,500 7.5 5,500
1,750 & 2,000 10.0 6,000
*Requirements are per module
