Aircel DHT-40 - 3.5 Preliminary Start-Up Checklist

VF, DHT, AES Series Manual |
Refrigerated Air Dryer User Manual
11
Incoming Water Flow Rate Requirements
(in gpm at dierent inlet water temperature)
Model by SCFM
Rating Condenser HP 70°F 80°F 85°F 90°F
100 0.50 1.50 1.75 2 C/F
125, 150 0.75 2.50 2.75 3 C/F
200 1.25 2.50 2.75 3 C/F
250, 300 1.50 4 4.50 5 C/F
400 2 5 5.50 6 C/F
500, 600 3.50 8 9 10 C/F
800 5 8 9 10 C/F
1,000 5 13 14.50 16 C/F
1,200 6 14 16 18 C/F
1,600 7 18 20 22 C/F
2,000 10 26 29 32 C/F
TABLE 3-4: Water-Cooled Water Flow Requirements- VF Series
TABLE 3-5: Water-Cooled Water Flow Requirements- DHT Series
Incoming Water Flow Rate Requirements
(in gpm at dierent inlet water temperature)
Model by SCFM
Rating Condenser HP 70°F 80°F 85°F 90°F
40,50 0.50 1.50 1.75 2 C/F
75,100 0.75 2.50 2.75 3 C/F
125 1.25 2.50 2.75 3 C/F
