Commissioning Data
Refrigerant Charging
It is important that the system is charged with the correct amount of refrigerant. Remember, a seriously over or
undercharged system may lead to major component failure.
The nal refrigerant charge level should be set by the design evaporating and condensing pressures, together with a full
or nearly full sight glass.
The suction and discharge pressures should be constantly monitored whilst charging is in progress.
To calculate the system refrigeration charge, please refer to the indoor unit data.
CR12 CR16 CR22 CR30
Refrigeration
Single Circuit
Refrigerant Type
R410A
Coil Volume
l 3.0 6.0 4.7 9.3
Refrigerant Charge
(1) kg 1.4 2.7 2.2 4.3
CR50 CR65 CR80 CR105
Refrigeration
Single Circuit
Refrigerant Type
R410A
Coil Volume
l 10.7 21.4 18.3 36.6
Refrigerant Charge
(1) kg 4.9 9.8 8.4 16.7
CR130 CR140 CR165
Refrigeration
Single Circuit
Refrigerant Type
R410A
Coil Volume
l 36.6 48.3 48.3
Refrigerant Charge
(1) kg 16.7 19.1 19.1
(1) For guidance only.
CR12 - CR165 50/60Hz CONDENSERS
32 Condenser Technical Manual 6666879 V2_02_2020
