AIREDALE CR12 - Electrical Data

Technical Data
Electrical Data
CR12 CR16 CR22 CR30
Mains Supply
(1) 230V / 1Ph + N / 50Hz
Unit Data
Nominal Run Amps
A 1.1 1.1 2.9 2.9
Maximum Start Amps
A 2.8 2.8 5.6 5.6
Recommended Mains Fuse
A 6 6 6 6
Max Mains Cable Incoming
mm² 6 6 6 6
Fan - Per Fan
Quantity
1 1 1 1
Motor Size
kW 0.22 0.22 0.63 0.63
Full Load Amps
A 0.97 0.97 2.9 2.9
Locked Rotor Amps
A 1.7 1.7 5.6 5.6
EC Condenser Fan - Per Fan
Quantity
1 1 1 1
Motor Size
kW 0.7 0.7 0.77 0.77
Full Load Amps
A 3.1 3.1 3.3 3.3
Mains Supply
(1) 230V / 1Ph + N / 60Hz
Nominal Run Amps
A 1.1 1.1 2.9 2.9
Maximum Start Amps
A 2.8 2.8 5.6 5.6
Recommended Mains Fuse
A 6 6 6 6
Max Mains Cable Incoming
mm² 6 6 6 6
Fan - Per Fan
Quantity
1 1 1 1
Motor Size
kW 0.24 0.24 0.63 0.63
Full Load Amps
A 1.1 1.1 2.9 2.9
Locked Rotor Amps
A 2.8 2.8 5.6 5.6
EC Condenser Fan - Per Fan
Quantity
1 1 1 1
Motor Size
kW 0.7 0.7 0.77 0.77
Full Load Amps
A 3.1 3.1 3.3 3.3
Mains Supply
(1) 220V / 2Ph / 60Hz
Nominal Run Amps
A 1.72 1.72 3.02 3.02
Maximum Start Amps
A 6.02 6.02 7.7 7.7
Recommended Mains Fuse
A 6 6 6 6
Max Mains Cable Incoming
mm² 6 6 6 6
Fan - Per Fan
Quantity
1 1 1 1
Motor Size
kW 0.39 0.39 0.64 0.64
Full Load Amps
A 1.72 1.72 3.02 3.02
Locked Rotor Amps
A 6.02 6.02 7.7 7.7
EC Condenser Fan - Per Fan
Quantity
1 1 1 1
Motor Size
kW 0.75 0.75 0.73 0.73
Full Load Amps
A 3.4 3.4 3.3 3.3
(1) Nominal data based on 35°C ambient and a 50°C mean condensing temperature and using standard fan.
CR12 - CR165 50/60HzCONDENSERS
23
Condenser Technical Manual 6666879 V2_02_2020
