Technical Data
Mechanical Data
CR95 CR105 CR130 CR140 CR165
Total Heat of Rejection CR (1) kW 109.9 113.2 149.7 150.1 195.7
Dimensions - Horizontal (2)
H x W x L mm
1167 x 1000 x
3560
1167 x 1000 x
3560
1167 x 1000 x
3560
1167 x 1000 x
4644
1167 x 1000 x
4644
Dimensions - Vertical (2)
H x W x L mm
1205 x 1167 x
3560
1126 x 1167 x
3560
1205 x 1167 x
3560
1126 x 1167 x
4644
1205 x 1167 x
4644
Weight
Machine kg 286 309 338 408 447
Condenser
Total Face Area m² 3.69 3.69 3.69 4.9 4.9
Nominal Airow m³/s 10.8 6.6 9.3 8.7 12.4
Discharge -H Horizontal or -V Vertical (Please Specify at Order)
Fan & Motor Axial - EC Axial - AC Axial - EC Axial - AC Axial - EC
Quantity 3 3 3 4 4
Diameter mm 710 630 710 630 710
Maximum Speed rpm 1030 860 1030 860 1030
Refrigeration - CR Single Circuit
Refrigerant Type R410A
Holding Charge Inert Gas
Coil Volume l 18.3 36.7 36.7 48.3 48.3
Refrigerant Charge (3) kg 7.2 14.5 14.5 19.1 19.1
Option
EC Fan
Designed to 75 Pa
ESP
Designed to 75 Pa
ESP
Dimensions – Horizontal
H x W x L mm -
1167 x 1000 x
3560
-
1167 x 1000 x
4644
-
Dimensions – Vertical
H x W x L mm -
1217 x 1167 x
3560
-
1217 x 1167 x
4644
-
Weight
Machine kg - 283 - 373 -
(1) Nominal data based on 35°C ambient and a 50°C mean condensing temperature and using standard fan.
(2) Overall dimensions for clearance; refer to Dimensional & Installation Data, for detail.
(3) For guidance only.
