AIREDALE CR12 - Mechanical Data

Technical Data
Mechanical Data
CR12 CR16 CR22 CR26 CR30 CR35
Total Heat of Rejection (1) kW 14.1 18.6 24.6 29.9 31.3 39.7
Dimensions - Horizontal (2)
H x W x L mm
972 x 1000 x
902
972 x 1000 x
902
1167 x 1000 x
1095
1167 x 1000 x
1095
1167 x 1000 x
1095
1167 x 1000 x
1095
Dimensions - Vertical (2)
H x W x L mm
1061 x 972 x
902
1061 x 972 x
902
1126 x 1167 x
1095
1204 x 1167 x
1095
1126 x 1167 x
1095
1204 x 1167 x
1095
Weight
Machine kg 69 78 96 106 110 119
Condenser
Total Face Area m² 0.59 0.59 0.92 0.92 0.92 0.92
Nominal Airow m³/s 1.3 1.1 2.3 3.3 1.9 2.6
Discharge -H Horizontal or -V Vertical (Please Specify at Order)
Fan & Motor Axial - AC Axial - EC Axial - AC Axial - EC
Quantity 1 1 1 1 1 1
Diameter mm 500 500 630 710 630 710
Maximum Speed rpm 910 910 860 1030 860 1030
Refrigeration Single Circuit
Refrigerant Type R410A
Holding Charge Inert Gas
Coil Volume l 3.0 6.1 4.7 4.7 9.4 9.4
Refrigerant Charge (3) kg 1.2 2.4 1.9 1.9 3.7 3.7
Option
EC Fan Designed to 75 Pa ESP
Dimensions - Horizontal
H x W x L mm
972 x 1000 x
902
972 x 1000 x
902
1167 x 1000 x
1095
-
1167 x 1000 x
1095
-
Dimensions - Vertical
H x W x L mm
1090 x 972 x
902
1090 x 972 x
902
1217 x 1167 x
1095
-
1217 x 1167 x
1095
-
Weight
Machine kg 73 81 88 - 101 -
(1) Nominal data based on 35°C ambient and a 50°C mean condensing temperature and using standard fan.
(2) Overall dimensions for clearance; refer to Dimensional & Installation Data, for detail.
(3) For guidance only.
