Technical Data
Mechanical Data
CR50 CR60 CR65 CR75 CR80
Total Heat of Rejection (1) kW 53.8 67.2 70.6 89.0 87.8
Dimensions - Horizontal (2)
H x W x L mm
1167 x 1000 x
2177
1167 x 1000 x
2177
1167 x 1000 x
2177
1167 x 1000 x
2177
1167 x 1000 x
3560
Dimensions - Vertical (2)
H x W x L mm
1126 x 1167 x
2177
1205 x 1167 x
2177
1126 x 1167 x
2177
1205 x 1167 x
2177
1126 x 1167 x
3560
Weight
Machine kg 167 187 198 217 257
Condenser
Total Face Area m² 2.15 2.15 2.15 2.15 3.69
Nominal Airow m³/s 4.8 7.0 4.2 5.7 7.5
Discharge -H Horizontal or -V Vertical (Please Specify at Order)
Fan & Motor Axial - AC Axial - EC Axial - AC Axial - EC Axial - AC
Quantity 2 2 2 2 3
Diameter mm 630 710 630 710 630
Maximum Speed rpm 860 1030 860 1030 860
Refrigeration Single Circuit
Refrigerant Type R410A
Holding Charge Inert Gas
Coil Volume l 10.7 10.7 21.5 21.5 18.3
Refrigerant Charge (3) kg 4.2 4.2 8.5 8.5 7.2
Option
EC Fan
Designed to 75 Pa
ESP
Designed to 75 Pa
ESP
Designed to 75 Pa
ESP
Dimensions - Horizontal
H x W x L mm
1167 x 1000 x
2177
-
1167 x 1000 x
2177
-
1167 x 1000 x
3560
Dimensions - Vertical
H x W x L mm
1217 x 1167 x
2177
-
1217 x 1167 x
2177
-
1217 x 1167 x
3560
Weight
Machine kg 150 - 180 - 231
(1) Nominal data based on 35°C ambient and a 50°C mean condensing temperature and using standard fan.
(2) Overall dimensions for clearance; refer to Dimensional & Installation Data, for detail.
(3) For guidance only.
CR12 - CR165 50/60HzCONDENSERS
21
Condenser Technical Manual 6666879 V2_02_2020
