AIRLESSCO 450 - Suction Assembly; 22 Suction Assy

20
21
SUCTION ASSEMBLY (331-238)
PARTS LIST FIGURE 22
Item No. Part No. Description
1 331-290 Suction Hose Assy
2 331-217 Inlet Strainer
3 331-035 Suction Elbow
4 331-034 Suction Nut
5 106-020
PTFE O-Ring
5
4
3
82
6
1
7
9
10
FIG. 22
PARTS LIST FIGURE 22 CONT
Item No. Part No. Description
6 331-231 Bypass Hose Assy
7 331-425 Bypass Hose
8 331-090R Fitting
9 111-016 Nylon Tie
10 331-135 Spring Clip
