Airoptic GasEye - 8.3.3.6. TEC -> Tec2; 8.3.3.7. TEC -> Tec3

WebServer application
GasEye Cross Duct
Operating i
nstructions,
0
5
/202
1
151
Figure 151. Laser temperature control module measurements window –
Laser2.
8.3.3.6. TEC -> Tec2
Submodule display measurement from third laser temperature control module.
Laser
measurement
s
Name
Description
TEC
2
.THL_REF_AMP
Reference gas amplitude
TEC
2
.AMB_TEMPERATURE
Laser ambient temperature
Table 21. Laser measurement list – Laser3 temperature control module.
Figure 152. Laser temperature control module measurements window -
Laser3.
8.3.3.7. TEC -> Tec3
Submodule display measurement from fourth laser temperature control module.
Laser
measurement
s
Name
Description
TEC
3
.THL_REF_AMP
Reference gas amplitude
TEC
3
.AMB_TEMPERATURE
Laser ambient temperature
Table 22. Laser measurement list – Laser4 temperature control module.
