OPERATING INSTRUCTIONS
15
Step 3: Remove the knife
Undo the locating screw with the provided hex key.
Remove the blade bracket.
Caution!!
Even used blades are extremely sharp!
Step 4: Change blade
Undo the little screw which fixes the blade with
the provided hex key.
Turn around the blade one time 180° or
apply a new one if both sides were already
used.
Fix the blade with the corresponding screw.
