AKG APS4 - 7 Technical Data

APS4 31
Technical data
A
PS4 Antenna Splitter
Type 2 x 1 to 4 receivers + 2 x 1 PS (for daisy-chaining)
Carrier range 470 to 952 MHz
A
ttenuation 0, 2, 4, 6, 8, 10, 12, 14 dB switchable
RF inputs 2 x BNC sockets, 50 ohms
RF outputs 10 x BNC sockets, 50 ohms
Power requirement 12 VDC
Size 200 x 190 x 44 mm (7.8 x 7.5 x 1.7 in.)
Weigh
t
approx. 970 g (2.2 lbs.)
A
B4000 Antenna Amplifie
r
Carrier range 500 to 865 MHz
Gain approx. 17 dB to 7 dB, selectable
RF inpu
t
1 x BNC, 50 ohms
RF output 1 x BNC, 50 ohms
Power requirement 10
VDC, supplied through connecting cable from APS4 or 8 VDC from
ASU4000
Size 110 x 35 mm (4.3 x 1.4 in.)
Weigh
t
approx. 150 g
(
5.3 oz.)
RA4000 B/W Active Omnidirectional Antenna
Carrier range 500 to 865 MHz
A
ntenna gain + booster gain 17 dB
RF inpu
t
1 x BNC socket, 50 ohms
RF output 1 x BNC socket, 50 ohms
Power requirement 10
VDC, supplied through connecting cable from APS4 or 8 VDC from
ASU4000
Size 78 x 50 x 50 mm / 3.1 x 2 x 2 in.
Weigh
t
68 g (2.4 oz.)
SRA2 B/W Active Directional Antenna
Carrier range 500 to 865 MHz
RF output 1 x BNC socket, 50 ohms
Power requirement 10
VDC, supplied through connecting cable from APS4 or 8 VDC from
ASU4000
A
ntenna gain + booster gain 21.5 dB
Coverage angle 70 °
Size 230 x 240 x 26 mm (9 x 9.5 x 1 in.)
Weigh
t
approx. 250 g (8.8 oz.)
A
SU4000 Remote Power Adapter
Carrier range 500 to 865 MHz
RF inpu
t
1 x BNC socket, 50 ohms
/
8 V DC
RF output 1 x BNC soc
k
et, 50 ohms
Power requirement 12 VDC
Size 78 x 50 x 50 mm / 3.1 x 2 x 2 in.
Weigh
t
approx. 167 g (5.9 oz.)
7 Technical data
