AKG C314 - Grand and Upright Pianos; Electric Guitar and Bass

30 C314
Using the Microphone
Grand and Upright Pianos
Figure 14: Grand piano
Grand piano:
Aim a single C314 or an XY, MS, or ORTF pair of C 414s at the middle strings
from a height of 5 to 7 feet (1.5 to 2 m).
For a rock/pop sound, place two C314s roughly 8 to 16 inches (20 to 40 cm)
above the strings. Align mic 1 with the treble strings and mic 2 with the bass
strings, both at point about 6 inches (15 cm) behind the dampers.
Figure 15: Upright piano
Upright piano:
Use the same technique as for the grand. Open the lid and have the microphones
"peek into the instrument" from above.
Electric Guitar and Bass
Figure 16: Electric guitar
