AKG C314 - 6 Technical Data

C314 33
Technical data
Type: 1” large dual diaphragm back-plate condense
r
Polar pattern: cardioid, supercardioid, omnidirectional, figure 8
Sensitivity: (cardioid): 20 mV/Pa
(
-34 dBV)
Frequency response: 20 Hz to 20 kHz (see frequency response trace)
Electrical impedance:
≤
200 ohms
Recommended load impedance:
≥
1000 ohms
Equivalent noise level to IEC 60268-4:
8 dB (A)
Signal to noise: 86 dB(A) at 1 Pa
Max. SPL for 0.5% THD:
135 / 155 dB SPL (0 / -20 dB)
Temperature range -10 °C +60 °C (14 °F -
140 °F)
Phantom powering: 48 V ±4 V to IEC 61938
Current consumption: ≤
3 m
A
Connector: 3-pin XLR (pin 2 hot)
Heigh
t
160 mm (6.3 in.)
Width 55 mm (2.16 in.)
Depth 43 mm (1.7 in.)
Net weight: 300 g (10.58 oz.)
Bass cut pad: 100 Hz, 12 dB/octave
Preattenuation pad: -20 dB
This product conforms to the standards listed in the Declaration of Conformity. To order a free copy of the
Declaration of Conformity contact sales@akg.com.
6 Technical data
