2 Description
25WMS 40 SINGLE/DUAL
2.5 HT 40 PRO
Handheld Transmitter
2.5.1 Controls
Refer to fig. 3 on page 2.
Note:
2.6 PT 40 PRO Body-
pack Transmitter
2.6.1 Controls
Refer to fig. 4 on page 2.
Note:
The HT 40 PRO handheld transmitter operates on a single fixed, quartz sta-
bilized frequency in the 710 MHz to 865 MHz UHF carrier frequency range
and uses an antenna integrated in the body.
The microphone element permanently mounted on the transmitter uses
a high quality cardioid transducer from AKG. It provides low handling noise
sensitivity, high gain before feedback, and brilliant sound quality, as well
as a built-in wind and pop filter to reduce wind and breath noise.
11 On/off switch: This slide switch provides three positions indicated in
the display window:
ON: Power to the transmitter is on.
MUTE: The signal delivered by the microphone element is muted while
power and the RF carrier frequency remain on.
OFF: Power to the transmitter is off.
12 Status LED: Indicates the transmitter's operating status.
LED lit green: Battery is OK.
LED lit red: From the moment the LED changes to red, the battery ca-
pacity will provide a maximum of two operating hours. We recommend
replacing the battery with a new one as soon as possible.
If you use a rechargeable battery, the LED will change to red 15 min-
utes before the battery will be dead!
13 Color code clip: The color of this plastic clip indicates the carrier fre-
quency of your transmitter. Receiver channels tuned to the same fre-
quency are marked with the same color. Refer to the Manual Supple-
ment sheet for a color code table.
You can remove the color code clip on the HT 40 PRO and replace it
with the supplied semitransparent clip.
14 Battery compartment lid: Refer to section 3.5.
15 Carrier frequency label: The label above the battery compartment in-
dicates the carrier frequency and approval marks of your transmitter.
You can use the PT 40 PRO bodypack transmitter with both dynamic mi-
crophones and condenser microphones operating on a supply voltage of
approx. 4 V. You may also connect an electric guitar, electric bass, or re-
mote keyboard.
The PT 40 PRO operates on a single fixed, quartz stabilized frequency in
the 710 MHz to 865 MHz UHF carrier frequency range.
16 On/off switch: This slide switch provides three positions indicated in
the display window:
ON: Power to the transmitter is on.
MUTE: The signal delivered by the microphone element is muted while
power and the RF carrier frequency remain on.
OFF: Power to the transmitter is off.
17 Status LED: Indicates the transmitter's operating status.
LED lit green: Battery is OK.
LED lit red: From the moment the LED changes to red, the battery ca-
pacity will provide a maximum of two operating hours. We recommend
replacing the battery with a new one as soon as possible.
If you use a rechargeable battery, the LED will change to red 15 min-
utes before the battery will be dead!
