Akuvox C313 Series User Manual

2
1.2. Power connection
The C313X is powered by simply connecting the two wires of the power
adapter to the wiring interface on the back of the indoor monitor.
C313X also support POE(Power Over Ethernet).
11 PIN connector
For power supply , RS485, Bell and Relay connector.
10 PIN connector
For 8 security connector
Ethernet 1
Network port with POE(Power over Ethernet),can be
connected to a hub, switch or other network access
devices.
Ethernet 2
Share the network access from Ethernet 1 port, and for
PC and other equipment connection.

Akuvox C313 Series Specifications

General

Audio	Built-in Microphone and Speaker
Installation	Wall-mounted
Ethernet	10/100Mbps
Relay Output	1
PoE	IEEE 802.3af
Power Supply	DC 12V or PoE
