Reassembly - Bottom Cover
Installer
17
Reassembly - Bottom Cover
Fasten the screws holding the outlet connector and
bottom cover
Slide back in the bottom cover plate
Carefully push the outlet connector down to its
home position
Pull the outlet connector up
Once the cable and pipe connections have been made, reassemble the bottom cover plates.
