Alcad 201 Series User Manual

55
VIDEO UNIT TCB-010
Make the terminal connections as shown. For more information consult the installation wiring diagrams at the back
of this manual.
Video signal ground
M
Video signal to the monitors
V1
Video signal multiple access ground
M
Video signal multiple access
V2
19
Made in Spain
TCB-010
cod. 9640000
V1
V2
MM
V1
V2
MM
19
Made in Spain
TCB-010
cod. 9640000
V1
V2
MM
V2
V1
MM
V1, M
V2, M
V2, M
19
Audio unit
Video signal to the monitors
V1, M
Internal
conductor
Mesh
COAXIAL
CABLE
Video unit (Multiple access installation)
Video signal to the monitors
Video unit (Multiple access installation)
Wiring diagrams:
19
Made in Spain
TCB-110
cod. 9640004
V1
V2
MM
V2
V1
MM
V3, M
V3, M
V3, M
19
Audio unit
Main entrance video unit accessory
V2, M
Buildings
TCB-010 TCB-010
Main entrance video unit accessory
Internal
conductor
Mesh
COAXIAL
CABLE
Video signal multiple access ground
M
Video signal multiple access
V2
Video signal estate ground
M
Video signal estate
V3
19
Made in Spain
TCB-110
cod. 9640004
V3 V2
MM
V2
V3
MM
VIDEO UNIT TCB-110
Make the terminal connections as shown. For more information, consult the installation wiring diagrams at the back
of this manual.
Description of terminals:
Wiring diagrams:
Description of terminals:
