Page 170 7450 ESS OS Basic System Configuration Guide
Initial System Startup Process Flow
Figure 7 displays the process start your system. Note that this example assumes that the boot
loader and BOF image and configuration files are successfully located.
Figure 7: System Startup Flow
SAVE CONFIG CHANGES
START
INSERT FLASH CARD INTO COMPACT FLASH SLOT #3
POWER CYCLE ROUTER
ESTABLISH ROUTER CONNECTION (CONSOLE PORT)
BOOT.LDR FILES FOUND
BOF FILES FOUND
CONFIGURE/MODIFY BOF FILE LOCATIONS
ASSIGN IP ADDRESS TO THE CPM
PRIMARY IMAGE
PRIMARY CONFIG
SECONDARY IMAGE
SECONDARY CONFIG
TERTIARY IMAGE
TERTIARY CONFIG
To Next Page
