Figure 20: Customer Use Example For LLDP
The example displayed in Figure 11 depicts a MPLS network that uses Ethernet interfaces in the
core or as an access/handoff interfaces to connect to different kind of Ethernet enabled devices
such as service gateway/routers, QinQ switches, DSLAMs or customer equipment.
IEEE 802.1ab LLDP running on each Ethernet interfaces in between all the above network
elements may be used to discover the topology information.
Ethernet Links - FE/GE/10GE
MPLS/Native ETH
Core
LAG
QinQ
SWs
DSLAMs
P
PE PE
PE PE
PE PE
P
SG/R
SG/R
