2. Read the SIP connection status (under the terminal's physical status).
The following table lists the different displayed status.
Displayed Status Meaning
Set not connected SIP phone disconnected from network / No
SIP registration request from the phone
SIP registration KO SIP registration request from SIP Phone rejec-
ted by Alcatel-Lucent OmniPCX Office Com-
munication Server
Set unregistered SIP phone unregistered from Alcatel-Lucent
OmniPCX Office Communication Server
SIP registration OK SIP phone connected and successfully re-
gistered to Alcatel-Lucent OmniPCX Office
Communication Server
4.5 8 Series Sets
4.5.1 IP Touch 4008/4018 Phone
4.5.1.1 Commissioning
4.5.1.1.1 Overview
This module presents all the actions required for commissioning:
- The Alcatel-Lucent IP Touch 4018 Phone set
- The Alcatel-Lucent IP Touch 4018 phone Extended Edition set
The commissioning of Alcatel-Lucent IP Touch 4018 Phone and Alcatel-Lucent IP Touch 4018
phone Extended Edition sets is identical.
The following figure illustrates the connectors on the base of the Alcatel-Lucent IP Touch
4018 Phone and Alcatel-Lucent IP Touch 4018 phone Extended Edition sets.
Chapter
4
&'(
4-58
