5.1 Detailed description
5.1.1 Default configuration
5.1.1.1 Alcatel-Lucent IP Touch 4038 Phone, Alcatel-Lucent IP Touch 4068 Phone
and Alcatel-Lucent 4039 Digital Phone sets
Each of these sets has 2 programmable keys (F1/F2) and 40 virtual add-on keys. Their default
functions depend on:
- The configuration of the set (Operator, Manager, Assistant, Normal or Attendant)
- The market in which the set is sold (US or non-US)
- The operating mode of the set (KeySystem or PABX mode)
The default functions of the F1/F2 keys are summarized in the table below (they are the same
for KeySystem and PABX modes).
table 5.1: F1/F2 Key Functions
Market Set Configuration Key F1 Key F2
Non-US Operator Normal/Restricted Mode Operator Diversion
Manager Secretary Screening
Secretary Manager Screening
Normal Call Call
US Operator Manual Hold Transfer
Manager Manual Hold Transfer
Secretary Manual Hold Transfer
Normal Manual Hold Transfer
The default functions of the virtual keys are summarized in the figures below (separate figures
are provided for the US market). The virtual keys are selected using 8 physical buttons, 4 on
each side of the set's display. There are 5 pages of virtual keys (the pages can be scrolled
through using the up/down buttons of the set's 4-way navigator), with 8 virtual keys on each
page. Each of the following figures shows the first page of virtual keys and then indicates the
progression to the last (fifth) page of virtual keys.
5-1
