Alcatel-Lucent OmniPCX Office RCE Small User Manual

3. Mode 3: Typical modification
4. Mode 4: Expert
5. Mode 5: Multisite
Important:
Access to modes 2, 3, 4 and 5 is password protected: pbxk1064 (using the OMC tool)
Access to modes 2 and 3 is password protected: help1954 (using the OMC Easy tool)
6.2.5.1 Mode 1: Data and tool repository
This mode is used to create .crp files offline (collective customer directories) which are used in
the Typical Installation menu.
6.2.5.2 Mode 2: Typical installation
This mode is used for online manual programming by choosing between Company and Hotel
and automatically on-line using .crp files.
Remark:
The choice Company/Hotel is only offered once. It is necessary to perform a cold reset to see it again.
6.2.5.2.1 Initial Business Installation Wizard
- IP configuration
- As of R9.1, DHCP configuration for:
• Alcatel-Lucent IP devices:
• Enabling/disabling DHCP server (enabled by default)
• Configuration of four DHCP IP address ranges (DHCP1 to DHCP4)
• Default values only for DHCP1 (192.168.92.10 to 192.168.92.39)
• Omniswitch:
• Enabling/disabling DHCP server (enabled by default)
• Configuration of one single DHCP IP address range (default values: 192.168.92.5
to 192.168.92.9)
- Default Numbering Plan
- Installation number
- Operating mode
- Channels and Bundles
- DECT ARI
- Creation of DECT handsets
- Metering
- Date and time
- Terminal List
- Various Subscribers
- Collective speed dial
- OS groups
Chapter
6
*
6-26
        

Alcatel-Lucent OmniPCX Office RCE Small Specifications

General

Users	Up to 50
Maximum Users	50
SIP Trunks Supported	Yes
VoIP Protocols Supported	SIP, H.323
IP Trunking	Yes
Storage Temperature	-20°C to 70°C
Type	IP PBX
Target Market	Small Businesses
Voicemail	Integrated
IP Phones Supported	Yes
Management Interface	Web-based, CLI
Physical Dimensions	440 x 44 x 280 mm
Power Supply	100-240V AC, 50-60Hz
Operating Temperature	0°C to 40°C
Relative Humidity	10% to 85% non-condensing

Summary

Chapter 1 General Presentation

1.2 Security

Information regarding security aspects, safety rules, and declarations.

1.3 Protection against Interferences

Guidelines and procedures for preventing and mitigating interference.

Chapter 2 Hardware: Platform and Interfaces

2.1 Overview

2.2 Platforms

2.4 Equipment

Information about available hardware boards and optional components.

Chapter 3 System Services

3.1 Software Licence Management

Management of software licenses, modes, and features.

3.2 Software Keys

Explanation of software keys, their types, and management.

3.3 Detailed description

3.4 Descriptions

Chapter 4 Installation and Cabling

4.1 Presentation

4.2 Connections and Cabling

Detailed descriptions and diagrams of system connections.

4.3 Power Supply

Procedures for installing and connecting power supplies and batteries.

4.4 SIP Terminals

Installation and commissioning procedures for SIP terminals.

4.5 8 Series Sets

4.6 9 Series Sets

4.7 V24/CTI Interface Module

Hardware description and connections for the V24/CTI module.

4.8 AP Interface Module

Hardware description and connections for the AP Interface Module.

4.9 S0 Interface Module

Hardware description and connections for the S0 Interface Module.

4.10 Intelligent Base Stations

Installation, configuration, and safety recommendations for base stations.

4.11 IP-DECT Base Stations

Detailed description and connection of IP-DECT base stations.

4.12 PIMphony

4.13 Reflexes Terminals

4.14 Extending Your Installation

4.15 My IC Social Networks

4.16 ACD applications

Chapter 6 Start-Up

6.1 System Startup from a Phone Set

Procedure for starting and configuring the system using a phone set.

6.2 System Startup from OMC

Procedures for starting and configuring the system using OMC.

Chapter 7 Maintenance Services

7.1 Maintenance Level 1

7.1.1 Maintenance

Detailed maintenance procedures for hardware.
