Alcoa 200 - Accessories; Service Parts Kit 42-236

200 Series Tooling Alcoa Fastening Systems
40
SERVICE PARTS KIT 42-236
Service Parts Kit 42-236 contains replacement parts needed when overhauling ONE Model 200
Tool, or forreplacing a damaged or worn 0-ring, etc.
Diaphragm
Deflector
Insert
Gasket
Spring, Air Valve
Spring
Wiper, Piston
Spring, Balance Valve
Seat, Ball Check ‘B”
Seat, Relief Valve
Spring, Ball Check
Seat, Balance Valve
Shim
Spring, Relief Valve
Ball Check Plug & O-ring Assembly
Seat, Ball Check ‘A”
Screw, Socket Head Cap #8-32 X 5/8
Screw, Socket Head Cap 1/4-20 X 3/4
O-ring AS 568-006
O-ring AS 568-008 Viton, 90 durometer
O-ring AS 568-010
O-ring AS 568-011
O-ring AS 568-012
O-ring AS 568-013
O-ring AS 568-014
O-ring AS 568-015
O-ring AS 568-020
O-ring AS 568-027
O-ring AS 568-111
O-ring AS 568-240
Retaining Ring, Truarc N5000-37
4-4
2-32
3-2
3-7
3-10
3-19
2-26
2-34
2-2B
2-3
2-52
2-4
3-9
2-48
2-49
2-2A
1-3, 1-5
1-6
2-45, 2-54, 4-3
1-2, 1-7
4-12, 4-14
2-36, 3-37
3-14, 16, 21, 25, & 50
3-11
3-38, 4-6, 4-9, 4-18
4-25, 4-31
3-47
2-10, 2-19, 2-29
2-5
3-3
2-43
100378
100341
100313
100346
100349
100353
111073
100381
100858
100859
100874
100889
100891
100968
104285
111139
500056
500071
500772
504547
500776
500777
500778
500779
500780
500781
500786
500793
500808
500872
500933
1
1
3
1
1
1
1
1
1
1
2
1
4
1
1
1
12
1
1
7
3
2
4
1
4
2
1
4
1
1
1
PART# QTY PART NAME REF. NO.
A
A
CCESSORIES
CCESSORIES
Table 10 - PARTS LIST
