NOTES:
1. All part numbers shown in this manual are
available from Huck. The 500000 series part
numbers are standard parts which generally
can be purchased locally.
2. O-ring sizes are specified as “AS” dash num
bers. (AS 568 is an AEROSPACE SIZE
STANDARD FOR O-RINGS and was formerly
known as ARP 568).
3. The compound for O-rings and Quad Rings is
SAE-ASTM SB715 BE, E
3
F
1
or F
2
(Nitrile or
Buna N, 70 Durometer, except as noted.
4. Back-up rings are either W.S. Shamban &
Co. Series S-11248 (MS-28774 TEFLON) or
Parker Seal Co. PARBAK Series 8. Dash
numbers correspond to AS dash numbers of
O-rings.
Table 10 - PARTS LIST (Continued)
Back-up Ring S-11248-06
Back-up Ring S-11248-07
Back-up Ring S-11248-10
Back-up Ring S-I 1248-27
Back-up Ring S-11248-111
Back-up Ring S-11248-114
Back-up Ring S-11248-211
Back-up Ring S-11248-213
Quad Ring MR-Q4114
Quad Ring MR-Q4213
Quad Ring MR-Q4011
Quad Ring MR-Q4006
Quad Ring MR-Q4007
Quad Ring MR-Q4111
Quad Ring MR-Q4211
Quad Ring MR-Q4342
Pin, Slotted .094 Dia. X .62
Retaining Ring, Truarc 5008-100
Ball, 1/4 Dia. Steel
Ball, 3/16 Dia. Stainless Steel
Ball, 11/32 Dia. Stainless Steel
Back-up Ring Parbak 8-007
Back-up Ring Parbak 8-014
Back-up Ring Parbak 8-015
Back-up Ring Parbak 8-111
Screw, Self-tapping #4-40 X 1/4
2-39, 2-46
2-42
4-11, 4-15
2-11, 2-20, 2-30
2-6
2-14
2-9
2-16, 2-23
2-13
2-15, 2-22
3-36
2-38
2-41, 4-23
3-6, 3-41
2-8, 2-27
3-45
3-30
3-48
4-19
2-47, 2-51
3-18, 3-22, 3-26
4-18
3-39, 4-8, 4-17
4-26
3-42
3-33
501078
501079
501082
501099
501102
501105
501138
501140
501170
501172
501408
501409
501410
501414
501417
501460
502135
502259
502509
502929
502934
503160
503167
503168
503195
504378
2
1
3
6
1
1
1
5
1
3
1
1
2
3
2
1
2
1
1
3
3
1
5
1
2
4
PART# QTY PART NAME REF. NO.
