MicrowaveradiorelaylinkZENITH80 
 25/52 1.2
3.7 ATTACHMENTOFFEEDERTOTHEANTENNA


Caution
Feeder can be damage while inexpert installation/deinstallation of ODU. Feeder is precise
element, manipulate it carefully. Any damage may cause iAPRoper function of the whole
link.

Feederandantennaareonewhole.Attachethefeedertotheantennaaccordingtothefollowingsteps
whendeliveredseparately:

• Checkthat“O”ringisslippedonfeeder.
• Attachthefeedertotheantennausing4M4bolts(figure16).


Figure16 AttachmentoffeedertotheAL1‐80/APR(AL2‐80/APR)antenna


CAUTION
Makesurethatflangesealing(“O”ring)isonitsplaceanditisnotdamaged.


Silicone„O“ring
Boltsattaching
feederM4x16
Feeder
