MicrowaveradiorelaylinkZENITH80
48/52 1.2
Parameter Value
Dimensionof3joinedterminalboxesALS1x(w×h×d) 482×44×138mm
ALS1xterminalboxdimensions(wxhxd) 162x44x135mm
ODUdimensions(withoutantennaradiatorandante nna)(wxhxd) 255x309x175mm
ODUweight(withoutantennaandantennaradiator) 6,5kg
Standards
EN60950
ETSIEN302217‐3
EN301751
ECCRec.(05)07
Table13 Technicalparameters
7.4 ENVIRONMENT
Operation
ALSx and ODU units surrounding environment must not contain aggressive vapors and gases, must
haveanormalradiationlevel,andbewithoutvibrationsandshocks.AllALSxandODUunitsareair‐cooled
bynaturalaircirculation.Theydonotcontainfansthatwouldsuckindirtfromsurroundingareasand
thus
lowerthereliabilityofthemicrowavelink.
The radio link is resistant against effects of wind with speeds of up to 33 m/s (120 km/h) without
influencetotransmissionquality.Reversiblechanges,i.e.,elasticdeformationoccuruptothewindspeed
of 56m/s (200km/h).Permanent deformation can
occur above this threshold, however, without damage
toODUitself.
The protected terminal box is intended for stationary use in locations protected against climatic
conditions.
ClimaticResistance
Surrounding
temperature
ALSx from‐25°Cto+55°C
Operationcapability
ODU from‐35°Cto+55°C
ALSx from‐25°Cto+55°C
Guaranteedparameters
ODU from‐33°Cto+50°C
Storageability ALSxandODU from‐25°Cto+55°C
Table14 Operationaltemperature
By operation ability we understand that the radio link can be operated within the specified
temperatures, but some parameters can deviate from specified limits. There will be no irreversible or
permanentchangeordamagetounitsinthespecifiedtemperaturerange.
TransportandStorage
Theradiorelaylinkunitscanbetransportedonlyincoveredvehiclesandtheunitsmustbeprotected
againstdirectweatherinfluenceatthesametime.Theyshouldbetransportedinsuitable(bestinoriginal)
packaginginordertopreventexcessiveloadsthroughshaking,vibrations etc., theyare not allowed to
be
