MicrowaveradiorelaylinkZENITH80 

 14/52 1.2

2.3 OUTDOORUNIT(ODU)



Figure6 TheODUconnectionplaces

The outdoor unit (ODU) with its microwave and data electronic modules is placed into a metal alloy 

box with cover allowing opening user terminal space needed for cable connection and diagnostics of the

link.ODUcanbeattachedtoAL1‐80/APRandAL2

‐80/APRantennasbyfourlatches.Feederisconnectedto

parabola.AntennasstaypointedwhenODUmustbedismounted.

Userterminalspace

Optionallygromet

ofthesecond

interconnecting

cableGEth2(Line2)

BoltM8

GroundingofODU

ConnectorBNC

OutputofU

RSSI

ODUTypeA/B

Serialnumber

MACaddress

TXfrequency

Grometof

interconnecting

cableGEth1(Line1)

Optionallyconnector

ofSFPmodul(Line4)

P/N

Type

N/V

Duplexspacing
