3. INSTALLATIONINSTRUCTIONS
3.1 STATIONINSTALLATION


Warning!
Low voltage equipment, electromagnetic and telecommu nication standards are applicable
toradiorelaylinkZENITH80.


Warning!
The radio relay link ZENITH  80 is not intended to be used by non‐specialist personnel.
Installation,adjustingandmaintenancemustbeperformedbythemanufacturerinstructed
personnelwithelectrotechnicalqualifications.

Allowedinstallationtorques:

Boltandnut Torque
M10 35Nm
M8 17Nm
M6 11Nm
M5 5Nm
M4 3Nm


Allboltsandnutsshouldbegreasedbeforeinstallation.

3.2 EVALUATIONOFSUITABLEPLACEMENT
Forinstallationandproperoperationoftheradiolinkthefollowingmustbeprovided:
 Directopticalvisibility
 PlaceforattachmentofantennawithODU
 AplacefortheprotectedterminalboxALS1x
 PathtolaytheODU–ALS1xconnectioncable
Guaranteeddirect visibility isnotalwayssufficient guarantee
of a quality connection.A condition for
atroublefreepropagationofelectromagneticwavesisapureradiovisibility.Iffixedobjects,liketreetops,
mountains or buildings are toocloseto the signalroute,they candistortor attenuatearadio signal.This
occurs even in cases when these
obstructions do not prevent direct visibility. This phenomenon can be
explainedbytheradiobeamFresnelzone–anellipticalareathatimmedia tely surroundsthedirectvisibility
axis(thelinebetweenlinkantennas).Sizeofthiszonevariesdependingonthehoplengthandradiosignal
frequency. The Fresnel zonemust
 be calculated before design of  the wirelesslink and it must beverified
thatitwillnotbedisturbedbyanyobstacles.
