MicrowaveradiorelaylinkZENITH80
9/52 1.2
Thedemodulatedsignalgoesfromthemodemtoamuldex,whereuserdata(Ethernet)areseparated
from the diagnostic data. The user data are sent to the protected terminal box again through the
overvoltageprotectionbyaconnectioncablewith4pairsofconductors.
ThevoltageontheRSSIconnector
(
figure6)isproportionatetotheintensityofthesignalreceivedfromtheoppositestation.Thisvoltage
determinestheheightofthe tone fortheacoustictransformerthatservesasanindicatorduring pointing
ofthelink.
2.1 TXPOWERREGULATION
The output power is set by manufacturer in conformity with maximum EIRP power condittions. EIRP
calculates with both Tran smitter output bower and antenna gain. There are two different concepts of
ZENITH80linkoutputpowerregulationconcept:
1. The basic possibility is to set output power from maximum 20 dBm in
steps of 1 dB and 20 dB
rangewithkeepingitstimeandtemperaturestability.Itispossibletosettheoutputpowerfrom
theASDdiagnosticprogram.Thepowerisregulatedanddisplaidbasedoninf o rmation fromlocal
transmitter.MicrowavepartofODUisequippedwithbranchwheretransmittedoutput
detection
circuit with microwave diode resides. Detected value is used both for Tx power regulation and
displaying.
2. Advanced function ofATPC (automatic transmit power control)is basedon regulation of output
poweraccordingtotheconditionsofelectroma gneticwavespropagation.Itdecreasestheoutput
powerduringoptimalconditionsandminimizes
possibilitiesofinterferenceswithotherlinks.The
power is regulated to the certain selected level based on receiver signal level from the remote
station.
