MicrowaveradiorelaylinkZENITH80 
 27/52 1.2
3.9 USERSPACECOVERHANDLING
TheuserspacecoverenablesaccesstotheuserinterfacesforconnectionanddiagnosticsofODUonly.
ThiseliminatesapossibilityofundesirableinterferenceintootherODUparts.

Thecoverisattachedby2M6boltsthatcanbeunscrewedbyanAllenwrenchno.5.Oneofthebolts
can
be only partiallyloosened, which ensures  attachment tothe boxduring manipulationwith the cover.
Retighteningofthisboltinopenpositionenableslockingofthelidinanyposition.

Since the user buses are located in the inside hermetically enclosed space of the box, the lid is
provided with
 a gasket.To protect the gasket from damage, please rigorously keep the safety notice
specifiedbelow.

Figure18 Manipulationwiththeuserspacecover

Warning
The bolt that ensures  attachment of the cover during manipulation must be loosened at
leastby1.5to2turnsduringmovingofthecover.Incasethattheboltistightenedduring
movingofthecovermoreorcompletely,thegasketisslidingovertheboxsharpedgesthat
candamagethegasketseriously.
Loosenthebolt
1,5‐2turns
