MicrowaveradiorelaylinkZENITH80 
 29/52 1.2


Figure19 Thegrommetinstallation
If a customer uses a different cable than the recommended type Cat 7 S‐STP by ACOME, the
installation is similar. If the cable has separate shielding for each pair of conductors, then the shielding
must be connected according to the marking on the Krone
connectors. In cables with only  one shielding
cabletakenouttheshieldingisconnectedtoanyshieldingpin.
Corresponding after installation tightness of the grommet must be ensured for these customer
selectedcablestoo.

CAUTION
ItisnotallowedtounscrewthegrommetfromtheODUwallunderanycircumstances.This
grommetishermeticallysealedandthissealwouldbedamagedduringdisassembly.
Caution!Donotloosewashersandaspringringifyoustraightenthebentshieldingofthe
connectioncableduringdisassemblyofthecable


Figure20 FinishedassemblyoftheconnectioncableCat7S‐STP
ODUZENITH80
ProtectedterminalboxALS1‐GEth
Foldedtopbraid
connectingcable
Contactspring
ring
Sealinggland
Topplate Bottomplate Capnut PVCcablecover
