aldes H/E280 - Mounting the Unit

Residential HRV/ERV
17
The following are typical items (sold separately) that may be used for standard installation.
Contact your local distributor to order Aldes items.
» Digital Multifunction Controller (P/N 611242-FC)
» Electronic humidistat with LCD (P/N 611227)
» Humidity Control (P/N 611224)
» 20/40/60 Minute Timer (P/N 611228)
» Speed Control (P/N 611229)
» Mode Control (P/N 611230)
» Wall-Mount Bracket (P/N 608575)
» Interior exhaust grilles
» Supply diusers
» Sleeves or register boxes for interior supply and exhaust
» Exterior wall hoods for supply and exhaust
» Insulated duct
» Uninsulated duct
» MR Modulo (constant airow regulators)
Mounting the Unit
The air exchanger is designed to be suspended from a structure or mounted against a
wall using the wall-mount bracket (sold separately, P/N 608575).
To suspend the device, affix the four mounting brackets in the upper corners of the unit.
Using the chains and the springs, suspend the air exchanger from the joists.
Suspended by chains Wall-Mount Bracket (P/N 608575)
Note: Models H/E190 and H/E280 cannot be installed using the wall-mount bracket.
