Assembling and operation HM80L
pressure.
7.5 Cross cut 90° and turntable 0° - 45°
The mitre saw can be used to make crosscuts of 0° -45° to the left and 0° -45° to
the right in relation to the fence.
Caution! For bevel cuts (inclined saw head), the moveable fence (17a) must be
xed in the outer position.
• Open the set screw (17b) on the moveable fence (17a) and push the moveable
fence (17a) outwards.
• Warning! The moveable fence (17a) must be locked in a position far enough
from the inner position that the distance between the fence (17a) and the saw
blade (7) is no more than 8 mm.
• Before making the cut, check that no collision could occur between the fence (17a)
and the saw blade (7).
• Tighten the set screw (17b) again.
• Adjust the turntable (15) to the desired angle. The pointer (13) on the turntable
(15) must match the desired angle on the scale (14) on the machine base (15).
• Cut as described under section 7.4.
7.6 Mitre cut 0°- 45° and turntable 0°
The mitre saw can be used to make mitre cuts of 0° - 45° in relation to the work
face.
Caution! To make mitre cuts (inclined saw head), the moveable fence (17a) must
be xed at the outer position.
• Open the set screw (17b) for the moveable fence (17a) and push the moveable
fence outwards.
• Warning! The moveable fence (17a) must be xed far enough in front of the in-
nermost position that the distance between the fence (17a) and the saw blade
(7) amounts to a maximum of 8 mm.
• Before making a cut, check that the moveable fence (17a) and the saw blade (7)
cannot collide.
• Secure the set screw (17b) again.
• Move the machine head (5) to the top position.
• Fix the turntable (15) in the 0° position.
• Loosen the set lever (21) and use the handle (2) to tilt the machine head (5) to
the left, until the mitre cut pointer (20) indicates the desired angle measurement
on the scale (19).
• Retighten the set lever (21).
• Cut as described in section 7.4.
7.7 Mitre cut 0°- 45° and turntable 0°- 45°
The mitre saw can be used to make mitre cuts to the left of 0°- 45° in relation to
the work face and, at the same time, 0° - 45° to the left or 0° - 45° to the right in
