210cc 4 stroke Petrol High Pressure Washer
AFTER SALES SUPPORT
(toll free) MODEL No.: SHW196 • 06/2019 9885
e-mail: info.aldi@positecgroup.com
AUS
31
1300 889 028
AUS
Manual start (see fig. N1-N5, O1-O2)
1) Pay attention to the symbols on the back machine near the choke
lever (28) and throttle lever (30).
2) To start the engine, follow the steps according to the two conditions
shown below:
c) Cold engine state: The washer is not used up for more than 1 hour.
Under this condition, move the choke lever (28) to the left. Be sure
to move it to the end.
d) Warm engine state: The engine has shut down for a short period
of time.Under this condition, move the choke lever (28) to the right.
Be sure to move it to the end.
NOTE: Sometimes the choke lever (28) needs to be moved to the
middle position as required.
3) Move the fuel valve (29) to the right. Be sure to move it to the end.
4) Move the throttle lever (30) a little to the left.
5) Push the spray gun safety lock (44) to release the trigger switch (41).
Squeeze the trigger switch (41) on spray gun (19) to release pressure.
Note: Do not install the nozzle when starting the machine.
6) Insert the electric start key (32) into the keyhole on the electric start
panel. Turn the key (32) to right to the “RUN” position.
7) Firmly hold the recoil starter (31) and pull it out slowly until
resistance is felt, then pull rapidly to start the engine.
8) Move the choke lever (28) a little to the right. Move to about 1/3
position. Then slowly move the choke lever (28) to the right during
the engine running process.
9)
During use, move the throttle lever (30) to left or right as required
to adjust the flowing speed.
O2
O1
